Well since upgrading my 99 Z51 shocks to the new 08 Z06 ones and feeling such a increase
in handling I decided to go with a pair of new swaybars and bushing.
Was looking at the C6 Z51 bars or the T1 bars, I think the C6 Z51 would be a mild improvement over the
stock bars and I have heard the T1's are great if drive your car on the track all the time
but you will feel the bump and the car will ride much harder.
So I decided to go with something in the middle of the performance spectrum and add a set of
Hotchkis bars and bushings along with a set of Z06 metal endlinks to firm things up a bit.

I will let you know how it turns out after my buddy Manny gets everything installed here are some photos
of the parts below.




Here also is a table of the approx bar sizes for the various OEM and aftermarket swaybar sets.

------------------------------
OEM
C5: 23.00mm front, 19.10mm rear / 3.81mm/2.0mm thickness
C5Z51 97-99: 25.40mm front, 21.70mm rear
C5Z51 00-04: 28.60mm front, 23.60mm rear / 4.15mm & 3mm thickness
C5 FE4/Z06: 30.00mm front, 23.60mm rear / 4.5mm & 3.5mm thickness
C5 T1: 38.40mm front, 27.50mm rear / 6.35 & 6.35 thickness
------------------------------
OEM
C6: 25.50mm front, 17.50mm rear
C6 Z51: 31.00mm front, 25.60mm rear
C6 Z06: 31.00mm front, 27.90mm rear
C6 T1, Race: 38.40mm front, 27.50mm rear / 6mm & ? thickness
------------------------------
Aftermarket
Hotchkis: 31.75mm front, 25.40mm rear
Addco: 32.00mm front, 25.40mm rear
Eibach: 29.00mm front, 25.00mm rear
Pfadt C5, Adj: 32.00mm front, 26.00mm rear
Pfadt C5, fatty: 35.00mm front, 29.00mm rear
Pfadt C6, street:34.90mm front, 25.40mm rear
Pfadt C6, fatty: 38.10mm front, 31.80mm rear


Riley P

Staff member
Moderator
Power User
Jan 11, 2009
11,032
1,909
Awards
8
Saska-ba-toon!
VetteCoins
12,066
Car
2000 Z51
Province
SK
Great Post Greg! I am very interested to hear how much the new sways will improve the ride and handling.


HiVoltge

Active Member
Feb 11, 2009
179
0
Awards
3
richmond hill
VetteCoins
300
Car
2000 MN6 Coupe
Great mod Greg!
I also recently upgraded my sways to Phadt bars and all I can say is wow! this is how these cars should have handled form the factory...I originally upgraded to Z06 bars 2 summers ago and that make a significant improvement over the base bars, but these aftermarket sways take it to a completely new level....

( I have the Z06 bars for sale BTW for any1 thats looking to upgrade their base suspension )


Riley P

Staff member
Moderator
Power User
Jan 11, 2009
11,032
1,909
Awards
8
Saska-ba-toon!
VetteCoins
12,066
Car
2000 Z51
Province
SK
Do you have the Pfadt Adj bars or the Pfadt fatty's?


not2melo

High RPM Poster
Feb 8, 2009
1,199
0
Awards
3
Greg in Toronto/Gtown
VetteCoins
310
Car
1999 C5 Z51
Great Post Greg! I am very interested to hear how much the new sways will improve the ride and handling.

Hopefully I will get them in my hands next week sometime and Manny can get a chance to throw them on for me.


not2melo

High RPM Poster
Feb 8, 2009
1,199
0
Awards
3
Greg in Toronto/Gtown
VetteCoins
310
Car
1999 C5 Z51
Great mod Greg!
I also recently upgraded my sways to Phadt bars and all I can say is wow! this is how these cars should have handled form the factory...I originally upgraded to Z06 bars 2 summers ago and that make a significant improvement over the base bars, but these aftermarket sways take it to a completely new level....

( I have the Z06 bars for sale BTW for any1 thats looking to upgrade their base suspension )

Ya, I hope the effect is much like the improvement with the new shocks!


Manny@Dasilva

Corvette Specialist
Power User
Feb 5, 2009
3,183
62
Awards
4
Cambridge
VetteCoins
303
Car
1998 C5 / 2015 Z06
Ya, I hope the effect is much like the improvement with the new shocks!

It will be very noticeable, as the body roll will be much less . Hey Greg ready when you are for a tims and early morning install :rofl:

TTYS
Manny@E.C.P

Last edited:

not2melo

High RPM Poster
Feb 8, 2009
1,199
0
Awards
3
Greg in Toronto/Gtown
VetteCoins
310
Car
1999 C5 Z51
Sounds good, will have coffee in hand, parts should be in late next week so most likely the following week.


Smokem

Casual User
May 2, 2010
24
46
Awards
2
Burnaby, BC Canada
VetteCoins
789
Car
1999 C5 convertible
I'm running these bars on my 99, It sure made it corner a lot flatter.
Don't forget to check the bolts after a few hundred k's mine came loose.


not2melo

High RPM Poster
Feb 8, 2009
1,199
0
Awards
3
Greg in Toronto/Gtown
VetteCoins
310
Car
1999 C5 Z51
Sounds good looking forward to the install.
I heard that before about rechecking the torque on the bolts
as they could come loose after a few hundred km's, thanks.


not2melo

High RPM Poster
Feb 8, 2009
1,199
0
Awards
3
Greg in Toronto/Gtown
VetteCoins
310
Car
1999 C5 Z51
Soon as I get the parts in my hands, they are in shipping now, then when
Manny can get a chance to throw them on, should only be a hour job or so.


BAD-C5

Active Member
Mar 10, 2009
387
0
Awards
3
Georgetown
VetteCoins
0
Car
2002 C5
Soon as I get the parts in my hands, they are in shipping now, then when
Manny can get a chance to throw them on, should only be a hour job or so.

Cool, lets us know what you think of the installed product.... That will be one of the next things I would like to do....:D


xlr8r

Power User
Apr 23, 2012
1,234
16
Awards
2
Alberta
VetteCoins
290
Car
2005
I'm sorry, rookie question.

What will sway-bars do? Just give a little less roll on the car when turning? I've never really looked into their function too much. Are the bushings always something you'd do when doing the sway-bars? I hope they aren't as pricey as the bushings on my Avalanche--thise were sick for price (OEM Electronic suspension).
