Welcome to 1965... Hockey night in Canada every weekend and Walt Disney on Sunday night. Back then I was glued to the TV as at 2 I was just learning to be the "remote control" for my Dad. I sucked at it but got better over the next few years I'm told.
Ok to the new model Corvette..
1965 CORVETTE OVERVIEW
As the 1965 model year approached, the design team behind the Chevy Corvette continued to refine the overall design of the
C2 Sting Ray, making only minor cosmetic changes in the process. Instead, the focus for the second-generation’s third year centralized on some significant mechanical upgrades that would vastly improve the Corvette’s already impressive handling and drivability.
At the same time, 1965 would also mark the beginning of the end of the second-generation Corvette as
Zora Arkus-Duntov and
Bill Mitchell each began championing the effort to develop a
third-generation Corvette, although each would bring with him a different interpretation of what that next-generation car would be.
Duntov’s group was actively seeking out ways to develop a mid-or rear-engine Corvette that was synonymous with cars like Porsche’s mid-engine Carrera GTS coupe.
By contrast,
Mitchell’s team had a different vision, one that would be fully realized in the development of the
Mako II Concept vehicle, a car that would eventually become known as one of the most famous concept vehicles of all time.
The XP-819 Corvette Concept was the first of many mid-engine Corvette designs presented by Duntov’s design group to Chevrolet in the 1960’s.
For
Duntov, the vision was to design a true mid-engine Corvette that could support a big-block Mark IV engine riding just ahead of the rear wheels. Duntov’s group developed a shape for their car’s fiberglass body, and even went so far as to assemble a couple of small-scale models in early 1965.
DID YOU KNOW:
The 1965 Mako Shark II was originally called just the “Mako Shark.” However, the moniker was changed to “Mako Shark II” after it was decided to retroactively rename the XP-755 prototype the “Mako Shark I”.
Ultimately, however, a rear- or mid-engine Corvette demanded specific mechanical components that General Motors simply did not provide. While the company had repeatedly attempted to produce a transaxle that was able to withstand the torque of a high-power V-8 engine, the design and the tooling expenses required to develop one that would be used only in a low-volume model would have sent Corvette prices skyrocketing beyond control. Still, it was decided that if General Motors could not entice consumers with a car that provided leading-edge technology, then Mitchell and company would introduce them to a car that had exotic styling.
The 1965 Mako Shark II Concept Corvette, designed by Bill Mitchell and Larry Shinoda.
Bill Mitchell had actually begun laying out the next generation Corvette in late 1964 with the help of Larry Shinoda and the General Motor’s design division. The intent from the onset had been to develop a car that could travel the auto-show circuit to serve as a trial balloon for the next generation Corvette. Mitchell instructed Shinoda that a suitable preview would have to be ready for the New York International Auto Show before April, 1965. In response to Mitchell’s request, Shinoda’s team of designers developed a full-size mock up of Mitchell’s next vision for the Chevy Corvette, which they dubbed the “Mako Shark II” (so named because of its long, somewhat flattened front-end, which made the car resemble a shark.)
The mock-up, which lacked an engine despite the hood label that read “Mark IV 396”, was rolled out for press release photography in March, 1965. A fully functional
Mark Shark II would follow shortly thereafter, fitted with a 427-cubic-inch Mk IV big-block V-8 engine.
The Mako Shark II included many of the design elements that would ultimately be
used to develop the third-generation Corvette.
Whether viewing the mock-up or the actual prototype, there was no question that the car looked fast. An aggressively pointed prow gave way to a domed hood that signified robust power. In both the mockup and the prototype, the bulging wheelhouses at all four corners of the Corvette only enhanced the already aggressive appearance of the car. Large, wide Firestone tires were wrapped around the wheels. The mockup featured cast-aluminum side exhaust with finned sidepipes that were painted in crackle black with “fins” which maintained a bright, polished finish. Changes to this exhaust system were made after the cars unveiling at the New York Auto Show (prior to the elimination of the side exhaust system from the prototype car completely.)
Measuring three inches longer than the existing Sting Ray, the “
Mako Shark II” featured a sleek roof -line that rolled back into a tapered exclamation point. That same bodyline continued all the way to the rear of the car, where a pronounced ducktail design defined the rear of the car. The entire car was painted using a careful feathering/blending of colors which only further helped to enhance the appearance that the “Shark II” was some sort of other-worldly design.
Using a blend of browns, blues (including Firefrost Midnight Blue) and grays, the car really started to represent the magnificent beasts of the sea from which so much inspiration was drawn for the car’s design.
The original design of the Mako Shark II’s interior included a rectangular steering wheel with
transmission controls built into it. This re-styled interior is what was included in the final conceptual design.
Even with the development of a new Corvette underway, the current, second-generation Corvette still had the immediate attention of Chevrolet’s executives. Given the sales success of the first two model years, there was little doubt by anyone that the 1965 Corvette would be equally successful, or perhaps even surpass previous successes. Given that fact, and the fact that Corvette’s best designers were focused on supporting the development of the next generation Corvette, Chevrolet was not making major modifications to the current model.
By all standards, the 1965 Mako Shark II was a futuristic vision of where Corvette design was headed.
That’s not to say there weren’t any changes made to the Corvette’s appearance. The most notable change to the outward appearance of the car was the removal of the former scoop indentations, which had carried over in the
1964 model (after the faux hood scoops were removed from the
1963 design.) The new hood, which was now a single, smooth surface, became one of the major differentiating characteristics of the 1965 model year.
In addition, the front fenders were redesigned to feature a trio of working exhaust vents (which replaced the previous model’s non-functional horizontal “speedline” coves.)
The 1965 Corvette hood is one of the most notable differences of the model year.
Note the complete absence of the hood scoops that were on the original 1963 model.
Another notable design change involved refinements to the front grill. For the 1965 model treatment; the inner, horizontal grill bars were painted black, but the outer grill remained a bright chrome color, making the overall design unique to the 1965 Corvette. Lastly, the wheel covers and rocker-panel moldings were re-designed for the 1965 model year. The optional knock-off wheel covers now featured a dark gray paint color between the fins.
The interior of the car also received some minor design refinements as well, though these were far more subtle than those made to the Corvette’s exterior. In the driver’s dashboard, all of the instrument displays were redesigned to include flat black faces.
Elsewhere, the areas around the radio and speaker bezel were now being painted, instead of utilizing the vinyl covering that had been standard on previous models. A more notable improvement involved another change in the design of the car’s driver and passenger seats. The new seating surfaces were designed to be slightly larger and more supportive, and the seat backs were now encased in hard plastic backing shells. Complementing the newly evolved seats, the inner door panels were also redesigned and now included fully integrated armrests. Lastly, the interior received new seat belt retractors, a feature that was never before been seen in a Corvette.
The 1965 Corvette Interior featured gauges with flat black faces and painted radio bezels.
The seats in the 1965 Corvette were redesigned to be slightly larger and more supportive.
A number of noteworthy alterations and additions were made for the 1965 model year – some of which would set a precedence that would carry over to the most current Corvette models being built today. The first of these welcome additions was the introduction of a standard, four-wheel disc brakes. The brakes featured a four-piston design with two piece calipers mated to a newly designed brake rotor which utilized cooling fins. The cooling fins helped to dissipate the massive amount of heat being generated during hard braking.
Suspended between the
calipers and
rotors was an all new semi-metallic brake pad. These pads were designed to remain in constant contact with the
brake rotors which aided in keeping the braking surfaces on the rotor free from rust and debris (both of which cause pitting and diminish the lifespan of any brake rotor.)
While the drag created by the contact between the pads and
rotors was negligible, the benefits of maintaining the rotor condition helped
GM to project a life expectancy of 57,000 miles on the front braking system (which, because of the forward weight transfer, supplied most of the braking effort in all-out stops.) Better still, the expected lifespan of the rear brakes was twice that of the front. Pending federal regulations (at/during the development phase of the 1965 Corvette), a dual master cylinder with separate fluid reservoirs for front and rear lines was also introduced. The newly designed master cylinder helped reduce the overall temperature of the brake fluid, which contributed to brake failure in older models.
The disc brakes were a much needed improvement over the previous braking system. Prolonged testing of the new disc brake system found that repeated stops from 100 miles per hour did not cause any deterioration in the efficiency of the braking system. Equally important was the fact that no matter the condition, all stops were very stable and required a much shorter braking distance than the earlier drum brakes.
Despite this, the old drum brake system did remain available to consumers and garnered a $64.50 credit on the overall Corvette purchase price when selected as an option. Despite this, only 316 Corvettes built in 1965 came equipped with the drum brake option.
The Mark IV Engine, available as RPO L78 was nicknamed the “porcupine motor”
because of its appearance, which many felt was reminiscent of porcupine quills.
Another significant improvement and mechanical milestone arrived midway through the 1965 model year. Officially titled the Mark IV, Chevrolet introduced a new, optional, big-block V-8 engine for the first time in a production Corvette.
The Mark IV had actually originated in early 1963 as the “mystery” 427 racing engine that had made its first appearance at the Daytona 500. Despite its official title, the engine was marketed as the Turbo Jet and was made available in three varieties, two 396 cubic inch versions, and a 427 (although a fourth, “heavy-duty” 427 was also created for marine use.)
The 396 big-block engines were scheduled to replace Chevy’s hallowed, though short-lived 409 cubic-inch by Semon E. “Bunkie” Knudsen (then General Manager of Chevy) that the only viable investment was to develop the most modern engine available, Chevy’s engine plant in Tonawanda, New York was retooled to support the production of the Mark IV engine. The engine officially began production in mid-1965. A number of variants of the Mark IV engine were produced. For its mid-size Chevelle model and all full-size Chevy models, a 325 horsepower and 360 horsepower engine was produced.
For the Corvette, however, the engine, which was available to consumers under RPO L78, was given 11:1 compression, impact-extruded alloy pistons with chrome rings, solid lifters, a bigger carburetor (and corresponding double-snorkel air cleaner) and an oversized oil pump, all of which helped make this more radical Mark IV engine capable of producing an impressive 425 horsepower.
The 1965 Mark IV Engine produced 425 horsepower.
The big-block also featured free-breathing cylinder heads with staggered valves that had been laid out in a seemingly disorganized fashion, with an appearance reminiscent to porcupine quills, which earned the engine the nickname, ‘the porcupine motor.”
The Mark IV engine was an immediate sensation and brought Corvette enthusiasts to their local Chevrolet dealerships in droves. While its introduction late in the model year resulted in limited supply, there was no questioning the long-term potential for an engine that was capable of producing such impressive performance numbers.
Even when equipped with a moderate 3.70:1 rear axle, a Mark IV equipped Corvette could do a standing quarter mile run right around 14 seconds at an impressive 104 miles per hour. Further, given adequate track distance, the car could now reach an overall top speed of nearly 140 mph (again when equipped with the 3.70:1 axle-ratio.)
Aside from the late-entry Mark IV, several other engines had remained available for the 1965 model year including a 375 horsepower, 327 cubic-inch small-block V8 that came equipped with fuel injection.
While this small-block engine was an impressive powerhouse in its own right, Chevrolet had definitely recognized that the direction of the powerplant for the Corvettes would center around engine displacement, and so it was decided that all other, smaller engines would ultimately be abandoned in the Corvette line at the end of the 1965 model year. Interestingly, the retirement of the 327ci engine also brought with it the end of the use of fuel injection in Corvettes for the next twenty years.
The 1965 Corvette Sting Ray Emblem.
Another new engine did appear in 1965 however. The L79 small block, which was essentially an L76 327 engine featuring a slightly milder hydraulic cam in place of the solid-lifter stick. Operating on an 11:1 compression ratio, the L79 engine was rated at 350 horsepower, and was deemed nearly identical to the L76 on the outside with its chromed air cleaner and finned cast-aluminum valve covers.
In all, the 1965 Sting Ray saw a total of 23,564 units sold, making 1965 the most successful sales year for the Corvette yet. Of all the units built, 15,378 were convertibles, accounting for nearly two-thirds of all Corvettes sold in 1965. By comparison, the coupe sold a mere 8,186 units.
)
